Why You Should Upgrade From Liquid Trap Magnets

Finger-style Inline Liquid Trap Magnets (also referred to as Finger Pot Magnets) are a conventional and often effective way of extracting foreign metal fragments from liquid lines such as chocolate, soup, beverages, and similar ingredients. The purpose of this post is to simply point out the advantages of further developments in liquid magnet separation, and how other solutions can benefit users of these devices.

WHAT ARE LIQUID TRAP MAGNETS?

Liquid Magnetic Traps for the food industry consist of a number of magnetic fingers/cartridges/tubes which are welded to a lid. The magnetic fingers are projected down into the flow and retain metal fragments as the liquid flows in, around, and out of the pot magnet housing. Whilst Magnattack Global can supply such devices in certain circumstances, the following opinions may be of assistance to anyone requiring magnets for separation metal fragments from liquids.

Following customer feedback relating to difficulty in handling bulk liquid magnet systems, the time taken to clean multiple finger bars, and an inherent issue with magnet fingers becoming bent or, in some cases, breaking off, Magnattack® Global identified the need to develop a modernized magnetic separation solution for use in liquids.

conventional-liquid-pot-magnetConventional Liquid Trap Magnet.
damaged liquid trap magnets - non-magnattack Damaged Liquid Trap Magnets.
A plant operator holds a Finger Pot MagnetLiquid Trap/Finger Pot Magnet lid.

THE SOLUTION: RE80® LIQUID PRESSURE PIPELINE SYSTEMS

After consulting with customers who were experiencing these difficulties, Magnattack Global developed the RE80™ Liquid Pressure Pipeline System (PPS). The Liquid PPS features +11,000 gauss magnet elements, designed to intercept the flow of liquid product lines. The RE80® probes successfully extract and retain foreign magnetic fragments such as work hardened stainless steel and stone particles, fine wear fragments, and rust.

The Liquid PPS Magnets offer hygienic and efficient magnetic separation and have proven to be a major success in efficiently removing foreign metal bodies from liquid lines in hundreds of applications over many years.

magnattack-liquid-pressure-pipeline-magnetic-separatorRE80® Liquid Pressure Pipeline Separator.
magnattack-liquid-pps-installedRE80® Liquid PPS installed.
magnattack-tear-drop-probe-magnetRE80® Acutex Probe Magnet, optional in Liquid PPS Systems.

LIQUID TRAP MAGNETS vs. RE80® LIQUID PRESSURE PIPELINE MAGNETS

This table provides a brief comparison of the problems associated with Liquid Trap Magnets, and how upgrading to Liquid PPS Magnets will assist you in overcoming these problems.
FINGER POT MAGNETS RE80® LIQUID PPS MAGNETS
CLEANING EFFICIENCY Finger Pot Magnets can present cleaning difficulties due to numerous 1" bars (typically 5-7 fingers). This has often resulted in contaminants being missed at cleaning intervals and has also made it difficult for operators to detect cracks or fatigue in the magnet fingers. Liquid Pressure Pipeline Separators feature only 2 x larger probes, therefore reducing cleaning and downtime. Each probe is removed individually, ensuring it is able to be fully inspected and cleaned before being returned to the product flow. This system can also be CIP cleaned prior to cleaning of magnets.
WHS/OHS Finger Pot Magnets are often heavy and the entire pot lid must be removed for cleaning. This can potentially result in operator WHS risks. Liquid PPS Probes are lightweight and operators need only to remove one probe at a time - therefore reducing the risk of injury caused by handling and lifting heavy equipment.
LEAKS & BLOCKAGES Finger Pot Magnets Lids are necessarily large to incorporate multiple bars, so more force over a larger area incurs more lbs per sq inch pressure, which may make them harder to seal than BSM or tri-clamp connections. Most housings are cast stainless steel which is magnetic. This can hinder the entry and exit of the magnets, making it difficult to align for a good seal. The Liquid PPS offers efficient magnetic separation without leaks, blockage, or distortion. Also available within the PPS range is the well proven and patented Acutex™ Probe Magnets, that assist in flowability and also minimize bulk density breakdown. BSM or Triclovers seals are used to securely seal probes to the housing, therefore reducing the risk of leakage.
DEAD-ZONES The 'dead-zone' in Finger Pot Magnets may provide a space for contaminants and product to rest - even when a drain is present. This is often unhygienic and risks magnetic contamination (and possibly bacteria) returning to the product flow. The sanitary construction of the Liquid PPS System and high-intensity magnet elements installed at right angles eliminate dead-zone and increase magnetic separation efficiency with over 80% coverage of product stream as required by Food Safety Standard 0909MAGSEP 1-2010. The openings can be opened and flushed during CIP and cleaning processes.
DAMAGE Breakage of magnet fingers is a frequently reported issue. Most Finger Pot Magnet designs consist of 1” diameter magnet bars welded to the lid. Often, fatigue and accidental dropping of the magnet results in magnet fingers becoming dented, bent, or broken. The Liquid PPS System is constructed using solid structural fixing, larger diameter bars, and structural welding techniques to avoid fatigue and breakage. In addition, the PPS comes with 3 years warranty on the magnet structural integrity.
COST EFFECTIVENESS In the case of 1 magnet finger becoming damaged, usually the entire pot lid and all fingers must be replaced. This can be a costly exercise. The Liquid PPS system is much more cost effective to repair as, in the unlikely event of damage, only 1 probe would need to be repaired or replaced.

Liquid Pressure Pipeline Magnets have been proven effective in a wide variety of applications, some of which include syrups, chocolate, soup, sauce, beverages, viscous pet food slurries, ice cream manufacturing, cheese processing, pie manufacturing, brine, fruit juice, and food paste.

With the development of advanced magnetic separation systems, such as the RE80® Liquid Pressure Pipeline Magnet, the food industry can be assured of the highest level of metal contamination risk reduction without risking important sanitary and food safety considerations!

As with all Magnattack® equipment, the Liquid PPS is certified by HACCP International and conforms to current industry food safety standards such as International Food Safety Standard 0909MAGSEP 1-2010.

CONTACT MAGNATTACK® - YOUR PARTNERS IN METAL FRAGMENT CONTROL

Magnattack Global technicians concentrate solely on the food, beverage, and pharmaceutical industries. This specialized focus ensures that we are able to provide a current, relevant, and knowledgeable source in regards to foreign metal fragment control.

Our #1 priority is to create effective solutions that will minimize your risk of metal contamination, food recall, and brand reputation damage.

For more information on the Liquid Pressure Pipeline System or other Magnattack® metal fragment control solutions, including the upgrade of existing Liquid Trap/Finger Pot Magnets, please contact us here.

In addition to the Liquid PPS Magnet, Magnattack Global also manufacture and supply the RE80® Magnet & Filter Combination (MFC). The MFC provides a unique solution which attracts and retains fine microscopic metal contamination that escapes filters.

Talk to a magnet expert today!
